Short Description
The Jackery Battery Pack 5000 Plus is a massive 5kWh expansion battery built for the Explorer 5000 Plus ecosystem. With LiFePO₄ chemistry, 4000+ cycles, and rugged build, it delivers long-lasting scalable power for whole-home backup, extended blackouts, and large off-grid setups.
Teaching Note
This expansion battery is designed for prosumers and heavy-duty users who need more than just backup — they need serious capacity. Each unit adds 5kWh, and when paired with the Explorer 5000 Plus system, it creates a powerful modular energy hub capable of supporting homes or even small business operations.
| Spec | Details |
|---|---|
| Model No. | JBP-5000A (only use with Explorer 5000 Plus) |
| Capacity | 5040Wh (45Ah / 112V DC) |
| Battery Chemistry | LiFePO₄ (Lithium Iron Phosphate) |
| Cycle Life | ~4000 cycles to ≥70% capacity |
| Weight | 81.6 lbs (37 kg) |
| Dimensions | 16.5 × 13.5 × 13.2 in (41.8 × 34.4 × 33.6 cm) |
| Max Short Circuit Current | 2600A / 5ms |
| Ingress Protection | IP20 |
| DC Expansion Port (Input) | 80.5V–126V ⎓ 41A max |
| DC Expansion Port (Output) | 80.5V–126V ⎓ 98A max |
| Charge Temperature | 0°C to 45°C (32°F to 113°F) |
| Discharge Temperature | -15°C to 45°C (5°F to 113°F) |
| Package Includes | Battery Pack 5000 Plus ×1, Expansion Cable ×1, User Manual ×1 |
| Warranty | 3 + 2 Years |
